Dongfeng 10m³ Foam Fire Truck

Dongfeng 10m³ Foam Fire Truck
Dongfeng 10m³ Foam Fire Truck
Dongfeng 10m³ Foam Fire Truck
Dongfeng 10m³ Foam Fire Truck
Dongfeng 10m³ Foam Fire Truck
Dongfeng 10m³ Foam Fire Truck
Dongfeng 10m³ Foam Fire Truck
1 / 7
Dongfeng 10m³ Foam Fire Truck
Dongfeng 10m³ Foam Fire Truck
Dongfeng 10m³ Foam Fire Truck
Dongfeng 10m³ Foam Fire Truck
Dongfeng 10m³ Foam Fire Truck
Dongfeng 10m³ Foam Fire Truck
Dongfeng 10m³ Foam Fire Truck
Chassis Configuration
Configuration Item Specification
Cab Type Double-row cab
Engine Yuchai 245 HP engine
Wheelbase 4700mm
Transmission 8-speed gearbox
Tyre Specification 295R80/22.5 18PR
Standard Equipment Factory-installed air conditioning, etc.
Upper Body Configuration
Configuration Item Specification
Total Tank Capacity 10m³
Water Tank 7.2m³ high-quality carbon steel tank
Foam Tank 2.5m³ 304 stainless steel tank
Fire Pump Shanghai Rongshen CB10/60 fire pump
Fire Monitor Chengdu Westers PS8/48 fire monitor
Power Take-off Full-power sandwich power take-off
Door Type Aluminum alloy rolling shutter doors
Control Panel Hydraulically openable integrated control panel (waterproof)
Standard Equipment Standard fire fighting equipment
