MERCEDES-BENZ 18 TON FOAM FIRE TRUCK TECHNICAL

1 / 2

Request a Quote Now

Get Quotation via Email Request Quotation via WhatsApp

Item	Specification
1. CHASSIS BASIC PARAMETERS
Chassis Brand & Model	Mercedes-Benz Actros 6x4
Drive Type	6×4 Rear Double Axle Drive
Cab Type	Double Row 4-door Crew Cab, 6 Seats Total
Wheelbase	3800 + 1450 mm
Overall Dimension (L×W×H)	10200 × 2500 × 3480 mm
Tire Specification	12.00R20 Heavy Duty Radial Tire, 10 pcs
Transmission Gearbox	Automatic Transmission
Steering System	Hydraulic Power Steering
Brake System	Full Air Brake with ABS & ASR Anti-slip System
Max Travel Speed	95 km/h
Emission Standard	Euro VI
2. ENGINE PARAMETERS
Engine Model	Mercedes-Benz OM470LA
Fuel Type	Diesel
Rated Power	350 kW / 476 HP
Displacement	12.8 L
Intake Mode	Turbocharged & Intercooled
Cooling Mode	Water Cooling
3. VEHICLE WEIGHT & LOAD CAPACITY
Gross Vehicle Weight (GVW)	32000 kg
Curb Weight	14000 kg
Rated Liquid Loading Capacity	18000 kg
Front Overhang	1500 mm
Rear Overhang	2450 mm
4. TANK & LIQUID CAPACITY
Water Tank Volume	15000 L
Foam Tank Volume	3000 L
Total Liquid Capacity	18000 L
Water Tank Material	High-strength Carbon Steel with Full Anti-corrosion & Anti-rust Treatment
Foam Tank Material	304 Food Grade Stainless Steel
Tank Structure	Built-in Wave Baffles, Reinforced Tank Body, Float-type Liquid Level Indicator
Tank Thickness	5mm Tank Body, 6mm Tank Head
Drain Valve	3-inch Stainless Steel Ball Valve
Manhole	500mm Diameter Sealed Manhole with Access Ladder
5. FIRE FIGHTING CORE PERFORMANCE
Fire Pump Model	Medium & Low Pressure Dual-purpose Fire Pump
Rated Pump Flow	50 L/s
Rated Working Pressure	1.0 MPa
Suction Depth	≥ 7 m
Self-priming Time	≤ 25 s
Fire Monitor	PL40 Water & Foam Dual-purpose Cannon
Rated Monitor Flow	40 L/s
Water Jet Range	≥ 65 m
Foam Jet Range	≥ 55 m
Monitor Rotation	360° Horizontal Rotation, -30° ~ +70° Vertical Pitch
Power Take-off (PTO)	Full Power Sandwich PTO
Foam Proportioning System	Automatic & Manual Dual Control Mixing System
6. STANDARD EQUIPMENT
Fire Fighting Accessories	Full set of fire hoses, suction pipes, quick couplings, spray nozzles & fire hydrant connectors
Warning & Lighting System	Roof red long row warning light, high-decibel 100W alarm siren, LED search working lamp & internal compartment lighting
Compartment Structure	Full aluminum alloy equipment compartments with lockable doors, independent pump room
Safety Protection Devices	Emergency stop device, pump overload protection, pressure relief safety valve, anti-freeze device
Rescue Hand Tools	Complete fire rescue hand tools, fire axe, crowbar, fire spade, 6m fire ladder
Pump Control System	In-cab + Pump Room Dual Control System, water circulation cooling system for pump operation
Pump System Accessories	Water filter, check valve, high-precision pressure gauge & flow meter
7. CERTIFICATION & AFTER-SALES TERMS
Main Certificates	CE, ISO9001, CCC, Vehicle Official Road Announcement Certificate
Warranty Period	12 months or 20,000 km from delivery date (whichever comes first)
Standard Production Lead Time	20–25 working days
Standard Loading Port	Shanghai Port / Wuhan Port, China
Optional Upgrade Items	Imported fire pump, wireless remote monitor control, fully automatic foam mixing system, thermal imaging camera
