1. Basic Vehicle Parameters (整车基本参数)

Item Specifications
Overall Dimensions (L×W×H) 7820 × 2380 × 3400 mm
Axles 2
Wheelbase 4200 mm
Tire Specification 8.25R20 16PR (Steel Wire Tires)
Emission Standard GB17691-2018 (China VI / Euro VI)
Engine Model Yunnei D40TCIF1
Engine Horsepower 185 HP
Displacement 4052 ml
Rated Power 135 kW

2. Chassis Configuration (底盘配置)

Feature Details
Model Dongfeng Furika F8 Heavy-duty Chassis
Transmission Fast 8-speed Manual Gearbox
Cab Type Semi-sleeper Cab (Extended Cab)
Rear Axle 8T High-load Capacity Rear Axle
Standard Features ABS, Central Locking, Electric Power Windows, A/C

3. Superstructure & Working Performance (上装参数与作业性能)

Item Performance Data
Superstructure Model GK45
Max. Working Height 45 Meters
Max. Working Radius 25m / 22m / 29m / 16m (Depending on load)
Platform Rated Load 100kg / 200kg / 300kg / 400kg
Boom Rotation Angle 360° Continuous Slew
Working Platform Size 3200 × 1000 × 1100 mm
Platform Rotation 360°
Boom Structure 9-Section Boom (8 synchronized telescopic sections)
Operation System Electronic Control System with Wireless Remote (Three-way operation)

4. Hydraulic & Stabilizer Systems (液压与支腿系统)

Feature Description
Hydraulic System Electro-hydraulic Proportional Valve; Stepless Speed Regulation
Emergency Power Equipped with Emergency Power Source (DC Pump)
Stabilizer Type X-Type Outriggers (4 units, 3-stage telescopic)
Stabilizer Span Lateral: 7.7m; Longitudinal: 7.3m
Walkway & Storage Anti-slip steel walkway with 4 oversized steel toolboxes

5. Safety Devices (安全保护装置)

  • Interlock System: Interlock between chassis outriggers and upper boom operations.
  • Limit Protection: Automatic stop at extreme positions.
  • Soft-leg Protection: Prevents operation if outriggers are not firmly grounded.
  • Tilt Alarm: Alerts operator if the vehicle inclination exceeds safety limits.
  • Emergency Power Source: Allows boom retraction in case of engine failure.
  • Hydraulic Balance: Two-way hydraulic balance valves for stable boom movement.
