FOTON 6T Wrecker Truck

FOTON 6T Wrecker Truck
FOTON 6T Wrecker Truck
FOTON 6T Wrecker Truck
1 / 3
FOTON 6T Wrecker Truck
FOTON 6T Wrecker Truck
FOTON 6T Wrecker Truck
Configuration Item Specification
1. Chassis Configuration
Cab Type Foton Aumark crew cab with forward-tilting function
Wheelbase 4700mm
Engine Cummins 220 horsepower engine
Gearbox Shaanxi Fast 8-speed gearbox
Tires 8.25R20 tires
Front Axle 4.6T front axle
Rear Axle 9T rear axle with 4.875 speed ratio
Leaf Spring Quantity 3/10+8 leaf springs
Gross Vehicle Weight 14055kg
Fuel Tank 200L aluminum alloy fuel tank
Standard Factory Components Original factory power take-off (PTO), original factory 3-layer through beam
Steering Wheel Multi-function steering wheel
Instrument Cluster LCD instrument cluster
Other Configurations The rest are in accordance with the standard chassis configuration
2. Upper Mounting Configuration
Upper Mounting Type One-tow-two upper mounting structure
Manufacturing Process Sunken upper mounting process (to lower the center of gravity of the flatbed)
Flatbed Dimensions Total length: approx. 6.5m, width: 2.55m
Tail Flip Length 1.2m tail flip section
Flatbed Material Made of 5mm wear-resistant checkered plate
Frame 14mm solid steel plate frame with cut holes
Tail Hinges Tail through-shaft detachable flip hinges
Slide Rails 10mm manganese steel slide rails (reinforced with 8mm steel plate bound outside the flared opening)
Under-Plate Reinforcement Dense grid-shaped reinforcement under the plate, dense triangular diagonal bracing
Winch 6-ton winch
Rear Support Arm 6-ton rear support arm
Hydraulic Valve Zhongmei hydraulic multi-way valve
Oil Cylinders 110-type flatbed telescopic oil cylinder, 110-type lifting oil cylinder
3. On-board Accessories
Gantry Side Lights 1 set of gantry side lights
Rear LED Work Lights 2 rear LED work lights
Lashing Straps 4 lashing straps
Triangular Tire Stoppers 1 pair of triangular tire stoppers
Square Tire Holding Tubes 1 pair of square tire holding tubes
L-shaped Forks 1 pair of L-shaped forks
Tool Box 1 tool box
