Item Specification
Engine Power Weichai 240 HP
Wheelbase 4700 / 5200 / 5600 / 6000 mm
Overall Length 9500 / 10000 / 10430 / 10930 mm
Overall Width 2500 / 2550 mm
Overall Height 3550 / 3650 / 3700 / 3800 / 3900 mm
Chassis Configuration
Cab Howo TX5 / TX-D Woying Version, multifunctional steering wheel, main airbag + auxiliary basic seat, middle cab seat
Powertrain WP4.6NQ240E62 Engine; HW95508STC2 Transmission + HW45ZC Flange-type PTO, cable-operated PTO
Axle 1094 self-adjusting front drum axle; MCJ09BGY single rear drum axle, final drive ratio 5.29
Frame & Suspension 3-layer reinforced frame(8+5+5/300); standard multi-leaf spring(10/9+8), front & rear cab spring shock absorber
Standard Fittings Sun visor, max speed 89km/h, cylindrical muffler exhaust, ABS(4S/4M), 10.1-inch HD MP5 touch screen, full-metal middle bumper
Tire & Fuel Tank 10.00R20 mixed tread tires, 18PR; 200L fuel tank
Electrical Parts 120AH battery, mechanical power switch, primary fuel filter, Sinotruk Smart D version
Crane Superstructure
Crane Model Changxing 8-ton 4-section boom, top control
Hydraulic System Single gear pump + dual control single pump, 360° full rotation, single outrigger
Auxiliary Devices Winch with rope arrangement motor, automatic rope retraction, remote start-stop, radiator
Flatbed Wrecker Body
Flatbed Rating 10-ton rollback flatbed (1-car towing)
Flatbed Size Total length 7.6m (including 1m tailgate), width 2.55m, sunk design for low gravity
Deck Structure 6mm high-strength wear-resistant checkered plate; 16mm perforated solid steel narrow border
Underframe 60×80mm horizontal square tube, dense triangle & grid bracing; double-layer manganese steel thickened slide rail
Rear Accessories Through-shaft hinged tailgate, 10-ton mid-mounted winch, 10-ton 3-section rear lifting arm mounted on main beam, 1 pair external air pipe
Hydraulic Parts Imported Italy HCD multi-way valve; 130mm HIDRA telescopic cylinder
