1. Chassis Specifications (底盘参数)

Item Specifications
Chassis Brand ISUZU
Engine Power 205 HP Diesel Engine
Transmission ISUZU MLD 6-speed Manual Transmission
Drive Type 4×2
Wheelbase 5550 mm
Axle Capacity Front: 6.3 Ton / Rear: 13 Ton
Tire Specification 295/80R22.5 18PR (Heavy-duty Tubeless)
Braking System Air Brake (Pneumatic)
Cabin Comfort Hot/Cold A/C, Power Steering, Central Locking, Electric Windows
Interior Technology Multi-function Steering Wheel, Multi-function LCD Instrument Cluster, ABS

2. Vehicle Performance (整车性能)

Item Data
Overall Dimensions 9820 × 2590 × 3950 mm
Curb Weight (Unladen) 17.2 Tons
Max. Working Height 45 Meters
Max. Working Radius 25m / 22m / 29m / 16m (Load dependent)
Main Boom Length 41.2 Meters
Slew / Rotation Angle 360° Continuous Slew

3. Working Platform & Boom (平台与臂架)

Item Specifications
Platform Model GKS45 Pro
Platform Rated Load 200kg / 300kg / 400kg
Platform Dimensions 3200 × 1000 × 1100 mm
Platform Type Foldable Aluminum Alloy Basket
Platform Rotation 360° Continuous Infinite Rotation
Boom Structure 8-Section Hexagonal Boom (7 sections synchronized telescopic)
Wire Rope Safety Dual-wire rope telescopic system with standby backup rope (Ensures safe lowering even if the main rope fails)

4. Control & Hydraulic System (控制与液压系统)

Feature Description
Operating System High-end Electronic Control with Wireless Remote & In-cabin Display Screen
Hydraulic Valves Electro-hydraulic Proportional Valves (Stepless speed regulation)
Emergency Backup Equipped with Emergency Power Source (DC Pump)
Stabilizer Type X-type Outriggers (4 units, 3-stage telescopic, individually adjustable)
Walkway / Decking Aluminum Alloy Anti-slip Walkway

5. Safety & Auxiliary Equipment (安全装置与辅助配置)

  • Interlock System: Safety interlock between outriggers and boom operations.
  • Emergency Power Source: Manual/Battery backup for boom retraction.
  • Hydraulic Protection: Two-way hydraulic balance valves.
  • Soft-leg Protection: Ground pressure sensing to prevent tipping.
  • Cooling System: Independent Hydraulic Oil Radiator.
  • External Power: 220V power socket on the platform for tools.
